Solenoid valve

Model: For water: DW- / For steam: DWS-

Valve size: DN15 – DN50

Materials: Brass valve body, Teflon diaphragm

Coil: Molded coil with alloy housing

Ingress protection: IP67

Operating temperature: Water: Max 80ºC; Steam: Max 180ºC

Working media: Water, hot water, compressed air, steam, etc.

Manufacturer: TPC

Origin: South Korea

Warranty: 12 months

Availability: In stock

Solenoid valve applications:

- Solenoid valves are used across a wide range of industrial and civil sectors, most notably in applications involving compressed air and fluids. Their functions include opening/closing, distributing, and mixing compressed air (from compressors) or hydraulic fluid (from hydraulic pumps).
- Common examples include washing machine water inlet and drain valves, reversing valves in reversible air conditioners, as well as applications in central air conditioning systems and fire protection systems.
